XH-SCT-T36-400A/200mA
Jiangyin Spark
The XH-SCT-T36 is a 400A/200mA split core current transformer designed for AC current measurement, energy monitoring and industrial power management applications.
Featuring a 36mm window opening and a 1:2000 current transformation ratio, this CT provides a 200mA secondary output at 400A rated primary current.
Its split core design allows installation around existing insulated conductors without disconnecting the primary wiring, making it ideal for new installations and retrofit energy monitoring projects.
400A rated primary current
200mA AC secondary output
1:2000 current transformation ratio
Accuracy 0.5
36mm window size
Split core design for easy installation
Suitable for AC current monitoring
Custom cable lengths and connectors available
OEM and ODM customization supported
| Parameter | Specification |
|---|---|
| Model | XH-SCT-T36 |
| Product Type | Split Core Current Transformer |
| Rated Primary Current | 400A AC |
| Rated Secondary Current | 200mA AC |
| Current Ratio | 1:2000 |
| Window Size | 36mm |
| Frequency | 50/60Hz |
| Wire lead | 1m UL1015 24AWG |
| Accuracy | 0.5 |
Energy Monitoring Systems
Smart Energy Meters
Industrial Power Monitoring
Building Energy Management Systems
Electrical Distribution Panels
Power Monitoring and Submetering
Retrofit Energy Measurement Projects
Jiangyin Spark Electronic Technology Co., Ltd. has manufactured current transformers since 1995.
We offer customized split core current transformers with different current ratios, output signals, cable lengths and connectors to meet various OEM and industrial applications.
Contact us for technical datasheets, samples and quotations.
